• Designed for paper and board makers
• Simple to use, accurate readings, excellent repeatability
• Wide moisture range
• Small spot size 10 mm in diameter
• Small size, light weight
• DCS interfaces: serial RS232, analog outputs, Profibus DP
• Data logging and analysis features
• Suits laboratory and field, QC and research
• Single-point or scanner use
• Based on Visilab's latest ultrastable technology
• A more protected version is available for most requiring positions
Main Features of AK50
• applications in pulp, paper and board industry, textiles, felts, filters, minerals, sawdust, recycled fiber
• for single-point or scanner use in on-line measurements, QC and troubleshooting
• simple to use but has useful features for advanced work
• surface moisture in thick samples, total moisture content in thin samples (abt. 150 microns penetration)
• accuracy 0.25 %, repeatability 0.1 % or better
• wide moisture range starting from 0 %, up to about 70 %
• infrared thermometer with signal available on all interfaces
• self-consistent, power supply included, ready to start
• fast response, selectable digital filtering, 400 points per sec sampling and updating of data
• superior stability, based on latest ultrastable infrared technology of Visilab
• available in two enclosure options: Either simply protected or with a an added protective nose, a Vortec cooler is a standard in both
